How I use it
The XR18 is the input for all my external audio gear: every synth I still have is plugged into it. It’s also the audio interface I record them through into Logic Pro. For hands-on mixing I control it from my X-TOUCH.
Specifications
| Inputs | 16 Midas-designed mic preamps (XLR/TRS combo jacks) 2 line/aux inputs (TRS) |
|---|---|
| Mixing | 18 input channels, 4 effects returns, 6 aux buses and main L/R 4 true-stereo effects engines |
| Outputs | Main L/R and 6 aux outputs (XLR) Headphones (TRS) |
| Audio interface | USB 2.0, 18 × 18 channels at 44.1 or 48 kHz |
| Converters | 24-bit; 40-bit floating-point processing |
| Connections | MIDI In and Out (5-pin DIN) Ethernet Ultranet Built-in Wi-Fi access point (up to 4 devices) |
| Power consumption | 30 W |
Specifications from Behringer’s XR18 page.
